INT-2270-M-01 Crompton The Integra 2270 Power quality meter

CROMPTON INSTRUMENTS INTEGRA 2270 POWER QUALITY METER


INTEGRA 2270 POWER QUALITY METER
Power to analyse quality, with a touch

The new Integra 2270 Power quality meter monitors - The quality of incoming electricity with a 0.2S% accuracy of reading

- Total Harmonic Distortion – the total distortion in the supply, measured as harmonics of the base frequency up to the 63rd harmonic.

- Waveform Capture – allows instantaneous events to be captured and analysed offline using a computer.

-  Voltage Interference – known as ‘sags and swells’. Variations in the voltage supply caused by non-linear loads, as described BS EN 50160:2010.


Key features

Signal conditioning
Patented* technology enables measurement of power quality within any voltage of electrical supply, in a single product, covering the global range 120/230V of electrical supplies.


Inputs and output

- Total measurement for all utilities in a single meter, including measurement of pulses from water and gas meters.

- Can be configured to communicate outputs relating to active and reactive energy to building management systems

- Alarms can be configured for any relevant, measured parameters and can also serve as a trip function


Full colour touch screen display

Energy-efficient and intuitive touch screen display with clear graphics and simple navigation. Easy for Field Engineers to set up and configure, reducing site time and saving money during installation.


Easy installation

Plug and socket connectivity for easy installation of prewired looms, saving valuable installation time and reducing wiring errors. Current flows directly through the meter primary CTs, meaning there is no need to terminate the CT wire at the meter.

The Integra 2270 digital meter provides measurement, isolation and conversion of all main electrical parameters and can be used in single-phase and three-phase three-wire unbalanced, four-wire balanced and unbalanced systems. RS485 Modbus RTU communications protocol, pulse/alarm outputs and inputs are fitted as standard.


Features (INT-2270 only)

- Waveform capture 8 cycles per phase
- Sags/swells monitoring to BS EN 50160
- Accuracy to 0.2S% (reading)


Features (all products)

- Full colour, energy efficient, touch screen user interface
- Patent pending signal conditioning technology
- Fits both ANSI and DIN cut-outs
- Alarm/pulsed output
- Pulsed inputs
- User programmable configuration
- Heart beat indication for self checking
- Min/Max value stored in non-volatile memory
- Individual harmonics measurement to 63rd harmonic
- Active power (kW) by phase
- Reactive power (kVAr) per phase
- Apparent power (kVA) per phase
- Current demand (AD) per phase
- Unbalanced voltage (%)
- Unbalanced current (%)
- Internal temperature measurement
- Hours run
- Supported real time clock
- Soft alarms
- Percentage of load bar for full scale indication
- User programmable display screen
- Accuracy to 0.5S% (reading)
- Sub cycle transient monitoring


Standards

EMC
IEC 61000-4-2
IEC 61000-4-3
IEC 61000-4-4
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-4-8
IEC 61000-4-11
IEC 61326-1, Class A
IEC 61000-3-2
IEC 61000-3-3

Safety
IEC 61010-1

Accuracy and Measurement
IEC 62053-21 class
IEC 62053-22 class 0.2S
IEC 62053-23 class 0.5S
ANSI C12.20


Features

- IEC 50160
  (sag/swells classes)
- EN60688
- ANSI C37.90.1
  (surge withstand)
- ANSI C62.41 (Burst)
- RoHS compliant


Product Codes

Integra 2270

INT-2270-M-01


Integra 2170

INT-2170-M-01



Specifications

- Nominal input voltage: 57.7V - 346V AC L-N (100 –600V L-L) 720V MAX
- Max. continuous input overload voltage: 120% of nominal
- Max. continuous input overload voltage: 2 x nominal voltage for 1 second
- Nominal input voltage burden: <0.5VA per phase
- Nominal input current: 1A AC or 5A AC RMS
- Nom. Input current burden: <0.1VA
- Max. continuous input overload current: 120% of nominal
- Max. continuous input overload current: 20 x nominal current for 1 second

Auxiliary
- Operating range: 110-250V AC/DC (+/- 20%) 45-66Hz (88-300V AC absolute limit)
- Supply burden: 10VA

Accuracy
- Voltage (V): 0.18% of reading + 0.02% nominal
- Current (A): 0.18% of reading + 0.02% nominal
- Neutral current calculated (A): < 1.0%
- Frequency (Hz): < 0.1 Hz
- Power factor (PF): ± 1% of unity
- Active power (W): ± 0.2S% of reading (at unity power factor)
- Reactive power (VAr): ± 0.2S% of reading (at unity power factor)
- Apparent power (VA): ± 0.2S% of reading (at unity power factor)
- Active energy (kWh): Class 0.2S (IEC 62053-22)
- Reactive energy (kVArh): Class 0.5S (IEC 62053-23)
- THD: 1%

Range
- Voltage (V): 20% to 120% of nominal
- Current (A): 1% to 120% of nominal
- Frequency: 45-66 Hz
- Power factor: 1 .. 0 lead or lag, 4 quadrant
- Active power: 5 to 144% of nominal
- Demand interval: 8, 10, 15, 20, 30, 60
- THD: up to 63rd harmonic
- Energy: 8 digit displayed in Wh, kWh, MWh
  (Maximum 9,999,999.9 MWh before rollover to 0.0)

Environment
- Operating temperature: -20°C to +60°C
- Storage temperature: -30°C to +80°C
- Relative humidity: 0-95% non-condensing
- Shock: 30g in 3 planes to IEC60068-2-6, 2g
- Vibration: 10Hz to 50Hz, IEC 60068-2-6, 2g
- Dielectric voltage: Withstand test 2.5kV, 50Hz for 1 minute between auxiliary/input/output
- IP protection (IEC 60529): IP 52 front display IP 30 product
- Altitude: Up to 2000m
- Installation category: CAT III
- Protection class: II
- Input waveform: Sinusoidal (distortion factor < 0.005)
- Magnetic field of external origin: Terrestrial flux
- Max wire gauge (input voltage, supply, I/O): AWG 12/2.5mm2
- Max wire gauge (current pass through): 0.177"/4.5mm

Display
- Size: 3.5" diagonal, 70mm x 52.5 mm
- Resolution: 320 x 240 RGB
- Colours: 16M
- Type: Touch screen (TFT)

Outputs Pulsed
- Pulse/alarm output relay (KYZ): User defined solid state relay
- Contact rating: 50mA max at 250VAC
- Isolation: 2.5 kV RMS
- Pulse duration: 60, 100, 200 msecs
- Pulse rate divisor range: 1 pulse per Wh up to 1 pulse per GWh
- Pulsed output parameter: Import/export kWh/kVArh
- Energy units: Kilo, mega, giga
- Max pulse rate: 2 pulses per second

Outputs (Alarm)
- Alarm trip and release: Any value in range
- Alarm type: User defined solid state relay, latched and unlatched
- Alarm delay: 0 - 600 second
- Delay resolution 10ms

Modbus™ Protocol
- Communication protocol: RS485 Modbus RTU
- Type: 2-wire half duplex
- Baud rate: 2900, 4800, 9600, 19200, 38400

Inputs
- Number of digital (pulsed) inputs: 2
- Voltage rating: Logic high threshold > 2 volts
- Logic low threshold < 1.2 volts
- Current rating: Logic high threshold > 0.5 mAmps
- Logic low threshold < 0.1 mAmps
- Max voltage limit: 30 volts
- Max frequency: 25 Hz
- Isolation: 2.5 kV RMS
- Detection: Rising, falling or both edges

Soft Alarms
- Number of soft alarms: 6
- Alarm parameter: Any practical Modbus parameter
- Alarm trip level: Any value in range
- Alarm release level: Any value in range
- Delay: 0 to 600 seconds (10 minutes)
- Output: Latched/unlatched


Other Features
- Internal temperature measurement: -20˚C to +60˚C
- Internal temperature accuracy: ± 2˚C
- Under/over/critical temp: User defined
- Real time clock: ± 2 seconds per day (1 sec intervals)
- Simultaneous waveform recording: 8 cycles of each phase (volts and amps)
- Sub-cycle transients: Voltage and current
- Resolution: 0.15 ms



Dimensions

- 100 x 70 x 118mm
- 3.94" x 3.11" x 4.65"
- Weight 0.42kg
- 92mm square DIN cut-out
- ANSI C39.1, 4" round



Connection Diagrams


3-phase 4-wire unbalanced


3-phase 3-wire unbalanced


1-phase 2-wire


1-phase 3-wire


Connection Detail
