Cảm biến quang điện khuếch tán 0.005-0.4m 10-30VDC red LED 3-wire NPN - Leuze - HT5.1/2 Diffuse sensor with background suppression

Thông số kỹ thuật

Basic data
Series5
Operating principle: Diffuse reflection principle with background suppression

Optical data
Black-white error: < 15% up to 200 mm
Operating range, white 90%: 0.005 ... 0.4 m
Operating range, gray 18%: 0.01 ... 0.3 m
Operating range, black 6%: 0.015 ... 0.2 m
Operating range limit: 0.005 ... 0.4 m
Adjustment range: 15 ... 400 mm
Light source: LED, Red

Electrical data
Protective circuit: Polarity reversal protection, Short circuit protected

Performance data
Supply voltage UB: 10 ... 30 V, DC, Incl. residual ripple
Residual ripple: 0 ... 15 %, From UB
Open-circuit current: 0 ... 15 mA

Outputs
Number of digital switching outputs: 1 Piece(s)

Switching output 1
Switching element: Transistor, NPN
Switching principle: Light switching

Timing
Switching frequency: 1,000 Hz
Response time: 0.5 ms

Connection
Connection 1
Function: Voltage supply, Signal OUT
Type of connection: Cable
Cable length: 2,000 mm
Number of conductors: 3-wire

Mechanical data
Dimension (W x H x L): 11.4 mm x 32.1 mm x 17.8 mm
Housing material: Plastic, PC-ABS
Lens cover material: Plastic / PMMA
Net weight: 50 g
Type of fastening: Via optional mounting device, Two M3 threaded sleeves

Operation and display
Operational controls: Multiturn potentiometer

Environmental data
Ambient temperature, operation: -40 ... 60 °C

Certifications
Degree of protection: IP 67
Protection class: III
Certifications: c UL US
Standards applied: IEC 60947-5-2

Classification
Customs tariff number: 85365019
eCl@ss 8.0: 27270904
eCl@ss 9.0: 27270904
ETIM 5.0: EC002719
ETIM 6.0: EC002719
