Siemens SKD82.50U | Electrohydraulic actuator -Bộ truyền động thủy lực điện tử 1000N 20mm 24VAC 9VA 3P UL 120s

Siemens SKD82.50U | Electrohydraulic actuator -Bộ truyền động thủy lực điện tử 1000N 20mm 24VAC 9VA 3P UL 120s

316
Nhà sản xuất:

Siemens

;

Xuất xứ: Germany

Giá sỉ:

Giá tốt nhất xem...0909186879 dienelectrics@gmail.com

Khuyến mãi:Có Discount
Bảo hành:12 Tháng (Chính hãng)
Thanh toán:C.O.D / Bảo lãnh TT / Link hoạt
Vận chuyển:Miễn phí Tp.HCM, vùng lân cận
Thông tin nổi bật

Bộ truyền động thủy lực điện tử Siemens SKD82.50U | Electrohydraulic actuator

(1000N 20mm 24VAC 3P UL 120s)


Overload-proof through travel-dependent, fixed switching off in end position. With die-cast aluminium housing and yoke for valves with 20 mm stroke. Optional functions: one auxiliary switch or one potentiometer. With manual control. UL listed.



Technical Specifications

Operating voltage AC 24 V, 24 V
Power consumption 9 VA
Positioning force 1000 N
Positioning signal 3-position
Positioning time 120 s
Stroke 20 mm
Spring return function No
Degree of protection IP54
Medium temperature -25…150 °C; 5…130 ºF
Ambient temperature, operation -15...50 °C
Mounting position Upright to horizontal


- Xem chi tiết Tài liệu kỹ thuật/ Datasheet Bộ truyền động thủy lực điện tử Siemens SKD82.50U
