SureSense Photoelectric retro-reflectives, Dòng cảm biến quang phản xạ hồi quy của Sick

Product family SureSense

Photoelectric retro-reflectives
The sure way to detect any object

- The most flexible and complete portfolio of hybrid sensors
- New and intuitive light strip
- Best background suppression in the sector
- Detection of transparent objects with AutoAdapt technology
- VISTAL housing

Photoelectric sensors SureSense

Photoelectric retro-reflectives


Ưu điểm

- Solve the vast majority of a customer's applications with a single sensor family
- Standardize mounting designs, accessories, set-up procedures and suppliers
- Fast and simple alignment during installation
- Continuous indication of signal strength
- Reliably sense objects of varying colors and materials
- Transparent object detection in tough environments with minimal need for additional cleaning
- Reduce replacement costs and down time due to damages during installation or use


Type: HL18BL-F4B5BH
Part number: 1101508
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PUSH/PULL, Light switching
Switching output Q2: PUSH/PULL, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18BG-F4B3BP
Part number: 1101631
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PUSH/PULL, Light switching
Switching output Q2: PUSH/PULL, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: Light/dark switching
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18B-F4B3BH
Part number: 1101380
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PUSH/PULL, Light switching
Switching output Q2: PUSH/PULL, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18B-P4B3AA
Part number: 1101632
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18B-M1G3AA
Part number: 1101633
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18B-L1G3AA
Part number: 1101635
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Light switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18L-P4A5BA
Part number: 1071025
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18L-P1G5BA
Part number: 1071027
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18L-P4A5BE
Part number: 1072411
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Male connector M12, 4-pin



Type: HL18-N4A3BG
Part number: 1072065
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Off delay, adjustable: 0 ... 2 s
Connection type: Male connector M12, 4-pin


Type: HL18-M1G3AA
Part number: 1072226
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-P4A2BA
Part number: 1071954
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P4A3BG
Part number: 1071755
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Off delay, adjustable: 0 ... 2 s
Connection type: Male connector M12, 4-pin


Type: HL18-P1G3BD
Part number: 1071773
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-P3A3BD
Part number: 1071767
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-P4A3BA
Part number: 1071743
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-B1G3BA
Part number: 1071765
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-N3A3BA
Part number: 1071763
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-A3A3BA
Part number: 1071772
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-N4A3BD
Part number: 1071771
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P2C3BA
Part number: 1071761
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: Not connected
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 300 mm


Type: HL18-P2E3BA
Part number: 1071762
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: Not connected
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 1,000 mm


Type: HL18-A4A3BA
Part number: 1071747
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-N4A3BA
Part number: 1071748
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-B4A3BA
Part number: 1071754
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P1G3BA
Part number: 1071757
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-A1G3BA
Part number: 1071752
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-N1G3BA
Part number: 1075814
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18L-P4A5BB
Part number: 1075008
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P4A3AAS06
Part number: 1081580
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P3A3BH
Part number: 1076627
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Male connector M8, 4-pin


Type: HL18G-P1G3BL
Part number: 1071040
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18G-P4A3BL
Part number: 1071037
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P4A3AA
Part number: 1070985
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18T-N1G3BB
Part number: 1074768
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18T-N4A3BB
Part number: 1074771
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18L-N1G5BA
Part number: 1074775
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18T-P1G3BB
Part number: 1074767
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18G-N4A3BL
Part number: 1074765
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18G-N1G3BL
Part number: 1074764
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18T-P4A3BB
Part number: 1074587
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-F3A3BD
Part number: 1073695
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PUSH/PULL, Light switching
Switching output Q2: PUSH/PULL, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-M1G3AD
Part number: 1073696
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18L-P4A5AA
Part number: 1071024
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18L-P1G5AA
Part number: 1071026
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18G-V1G3BL
Part number: 1072225
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Health output
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18G-V3A3BL
Part number: 1071953
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Health output
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-V4A3AA
Part number: 1071769
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Health output
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P4A2BK
Part number: 1071462
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: Light/dark switching
Connection type: Male connector M12, 4-pin



Type: HL18L-B3G5BE
Part number: 1071028
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Cable with M8 male connector, 4-pin, 2,000 mm


Type: HL18G-P4A3BM
Part number: 1085852
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: On delay, adjustable: 0 ... 2 s
Connection type: Male connector M12, 4-pin


Type: HL18-F4A3BDS20
Part number: 1102663
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PUSH/PULL, Light switching
Switching output Q2: PUSH/PULL, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P2B3BA
Part number: 1071760
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: Not connected
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 150 mm


Type: HL18L-P3A5BA
Part number: 1082242
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18G-A2B3BL
Part number: 1084977
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: Not connected
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 150 mm


Type: HL18G-P3A3AL
Part number: 1083544
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18L-P3B5BA
Part number: 1080745
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with M8 male connector, 4-pin, 150 mm


Type: HL18-J4A3BH
Part number: 1081856
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: PNP, Alarm output
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Male connector M12, 4-pin


Type: HL18T-P3A3BB
Part number: 1080597
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-A4A2BE
Part number: 1080595
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P3B3BE
Part number: 1080548
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Cable with M8 male connector, 4-pin, 150 mm


Type: HL18-N4B3BA
Part number: 1080377
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18G-M1G3AL
Part number: 1080322
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-P4C3BA
Part number: 1080351
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 300 mm


Type: HL18T-P2G3BB
Part number: 1079923
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: Not connected
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 2,000 mm


Type: HL18-N4A3BH
Part number: 1079886
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Male connector M12, 4-pin


Type: HL18T-N3A3AB
Part number: 1082591
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-F4B3BB
Part number: 1079109
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PUSH/PULL, Light switching
Switching output Q2: PUSH/PULL, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18-A4B3BH
Part number: 1082986
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18-B1E3BB
Part number: 1088137
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 1,000 mm


Type: HL18-A1G3BH
Part number: 1082987
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Cable open end, 2,000 mm


Type: HL18-B1E3BE
Part number: 1083177
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Cable open end, 1,000 mm


Type: HL18-B1G3BB
Part number: 1088138
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-A4A3BH
Part number: 1086123
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Male connector M12, 4-pin


Type: HL18-A4B3BA
Part number: 1085979
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18-B1G3BE
Part number: 1083176
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-F4A3AA
Part number: 1088982
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PUSH/PULL, Light switching
Switching output Q2: PUSH/PULL, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-B4A3AE
Part number: 1088983
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18G-A2B3BP
Part number: 1084991
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: Not connected
Potentiometer, right: Teach-in
Potentiometer, left: Light/dark switching
Connection type: Cable with connector M8, 3-pin, 150 mm


Type: HL18G-M5G3AM
Part number: 1081955
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: On delay, adjustable: 0 ... 2 s
Connection type: Cable with connector, Micro (1/2-20), 4-pin, 2,000 mm


Type: HL18G-M5G3AP
Part number: 1084568
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: Light/dark switching
Connection type: Cable with connector, Micro (1/2-20), 4-pin, 2,000 mm


Type: HL18-F4G3BD
Part number: 1083630
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PUSH/PULL, Light switching
Switching output Q2: PUSH/PULL, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 2,000 mm


Type: HL18G-A1G3AL
Part number: 1082073
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18G-A1G3BL
Part number: 1082038
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18G-A2B3AL
Part number: 1084976
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: Not connected
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 150 mm


Type: HL18G-N3A3BM
Part number: 1088878
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: On delay, adjustable: 0 ... 2 s
Connection type: Male connector M8, 4-pin


Type: HL18G-N3A3BL
Part number: 1085238
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18G-N3A3BN
Part number: 1088879
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: Off delay, adjustable: 0 ... 2 s
Connection type: Male connector M8, 4-pin


Type: HL18G-N4A3BM
Part number: 1085125
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: On delay, adjustable: 0 ... 2 s
Connection type: Male connector M12, 4-pin


Type: HL18-L5B3AF
Part number: 1081785
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Light switching
Potentiometer, right: Sensitivity
Potentiometer, left: On delay, adjustable: 0 ... 2 s
Connection type: Cable with connector, Micro (1/2-20), 4-pin, 150 mm


Type: HL18-L5B3AH
Part number: 1086665
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Light switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Cable with connector, Micro (1/2-20), 4-pin, 150 mm


Type: HL18-L1G2AG
Part number: 1088839
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Light switching
Potentiometer, right: Sensitivity
Potentiometer, left: Off delay, adjustable: 0 ... 2 s
Connection type: Cable open end, 2,000 mm


Type: HL18G-P4B3BL
Part number: 1081918
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18-L1G3AG
Part number: 1088848
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Light switching
Potentiometer, right: Sensitivity
Potentiometer, left: Off delay, adjustable: 0 ... 2 s
Connection type: Cable open end, 2,000 mm


Type: HL18-L5B3AB
Part number: 1084526
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Light switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable with connector, Micro (1/2-20), 4-pin, 150 mm


Type: HL18L-P3A5AE
Part number: 1082241
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18L-P3A5BE
Part number: 1082243
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18L-P4A5AE
Part number: 1082244
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18L-A4A5BB
Part number: 1083753
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18L-P4A5BH
Part number: 1084269
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Male connector M12, 4-pin


Type: HL18L-A4A5BE
Part number: 1081368
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18L-B2E5AB
Part number: 1086094
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: Not connected
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 1,000 mm


Type: HL18L-P3A5AA
Part number: 1082240
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18L-A4A5BA
Part number: 1082084
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-N4A3BC
Part number: 1088259
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: On delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-N1G2BB
Part number: 1084762
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-N4A3BF
Part number: 1085292
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: On delay, adjustable: 0 ... 2 s
Connection type: Male connector M12, 4-pin


Type: HL18-L5G3AE
Part number: 1087806
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Light switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Cable with connector, Micro (1/2-20), 4-pin, 2,000 mm


Type: HL18-N1G3BB
Part number: 1084770
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-N4A3BB
Part number: 1084894
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-N3A3BB
Part number: 1084641
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-M1G3AH
Part number: 1088646
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Cable open end, 2,000 mm


Type: HL18-M5B3AB
Part number: 1082055
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable with connector, Micro (1/2-20), 4-pin, 150 mm


Type: HL18-P4A3AF
Part number: 1081784
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: On delay, adjustable: 0 ... 2 s
Connection type: Male connector M12, 4-pin


Type: HL18-P4A3AG
Part number: 1088212
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Off delay, adjustable: 0 ... 2 s
Connection type: Male connector M12, 4-pin


Type: HL18-N1G3BH
Part number: 1087213
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Cable open end, 2,000 mm


Type: HL18-P3B3BA
Part number: 1082609
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with M8 male connector, 4-pin, 150 mm


Type: HL18-P3A3AA
Part number: 1088529
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-M1G3AE
Part number: 1085233
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Dark switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-P3C3BA
Part number: 1088537
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with M8 male connector, 4-pin, 300 mm


Type: HL18-P4A2BB
Part number: 1081196
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P3A2AA
Part number: 1088528
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-P2E3BH
Part number: 1088045
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: Not connected
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Cable with connector M8, 3-pin, 1,000 mm


Type: HL18T-P4B3BB
Part number: 1083488
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18T-N4A3BH
Part number: 1083398
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Male connector M12, 4-pin


Type: HL18T-N4A3BG
Part number: 1086995
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Off delay, adjustable: 0 ... 2 s
Connection type: Male connector M12, 4-pin


Type: HL18-N4B3BB
Part number: 1086953
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18T-N4B3BH
Part number: 1083397
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18-P4B2BB
Part number: 1086065
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18-P4B3BB
Part number: 1083167
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm

Type: HL18T-N4B3BB
Part number: 1081806
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18-P2E3BE
Part number: 1081369
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: Not connected
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 1,000 mm


Type: HL18T-A4A3BH
Part number: 1087971
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Male connector M12, 4-pin


Type: HL18-P4A3BF
Part number: 1087364
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: On delay, adjustable: 0 ... 2 s
Connection type: Male connector M12, 4-pin


Type: HL18T-B2E3AB
Part number: 1086095
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: Not connected
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 1,000 mm


Type: HL18T-N4A3BF
Part number: 1085855
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: On delay, adjustable: 0 ... 2 s
Connection type: Male connector M12, 4-pin


Type: HL18-A1G3AA
Part number: 1071000
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18T-B4A3BH
Part number: 1080225
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Male connector M12, 4-pin


Type: HL18-B4B3BE
Part number: 1079121
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18-B4A3BH
Part number: 1079905
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Male connector M12, 4-pin


Type: HL18-P3B3BD
Part number: 1079778
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Cable with M8 male connector, 4-pin, 150 mm


Type: HL18-F4A3BD
Part number: 1080328
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PUSH/PULL, Light switching
Switching output Q2: PUSH/PULL, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18G-F4A3BN
Part number: 1080329
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PUSH/PULL, Light switching
Switching output Q2: PUSH/PULL, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: Off delay, adjustable: 0 ... 2 s
Connection type: Male connector M12, 4-pin


Type: HL18G-B4A3AL
Part number: 1080257
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P4B3AA
Part number: 1084038
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18-A4B3AE
Part number: 1092075
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18T-A4A3BF
Part number: 1092798
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: On delay, adjustable: 0 ... 2 s
Connection type: Male connector M12, 4-pin


Type: HL18-A2B3BC
Part number: 1090997
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: Not connected
Potentiometer, right: On delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 150 mm


Type: HL18-A2B3BA
Part number: 1090938
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: Not connected
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 150 mm


Type: HL18L-F1G5BB
Part number: 1091311
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PUSH/PULL, Light switching
Switching output Q2: PUSH/PULL, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-P4A3BC
Part number: 1091085
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: On delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-A2B3BD
Part number: 1090936
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: Not connected
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 150 mm


Type: HL18-B2B3BD
Part number: 1090937
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: Not connected
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 150 mm


Type: HL18G-N3A3BP
Part number: 1092210
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: Light/dark switching
Connection type: Male connector M8, 4-pin


Type: HL18G-A4A3BP
Part number: 1090238
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: Light/dark switching
Connection type: Male connector M12, 4-pin


Type: HL18-A2B3BB
Part number: 1094160
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: Not connected
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 150 mm


Type: HL18-X4A3AA
Part number: 1094390
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: PNP, Health output
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18T-P4A3BG
Part number: 1093236
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Off delay, adjustable: 0 ... 2 s
Connection type: Male connector M12, 4-pin


Type: HL18T-P3A3BG
Part number: 1093149
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Off delay, adjustable: 0 ... 2 s
Connection type: Male connector M8, 4-pin


Type: HL18G-P4B3BN
Part number: 1093458
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: Off delay, adjustable: 0 ... 2 s
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18G-P2B3BL
Part number: 1092901
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: Not connected
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 150 mm


Type: HL18L-F4A5BE
Part number: 1094842
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PUSH/PULL, Light switching
Switching output Q2: PUSH/PULL, Dark switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P4A3AE
Part number: 1092921
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-X4A3BA
Part number: 1082932
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: PNP, Health output
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P3A2BB
Part number: 1079074
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18T-P4A3BH
Part number: 1078824
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Male connector M12, 4-pin


Type: HL18-A4A3BE
Part number: 1080715
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P4A3BE
Part number: 1078823
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P4A2AA
Part number: 1080683
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P4A3BH
Part number: 1098007
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Male connector M12, 4-pin


Type: HL18-P4A3BAP01
Part number: 1084297
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-M1K3AA
Part number: 1097015
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 3,000 mm


Type: HL18T-P3B3BB
Part number: 1095544
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable with M8 male connector, 4-pin, 150 mm


Type: HL18T-A1K3BB
Part number: 1098305
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 3,000 mm


Type: HL18-P4A3BI
Part number: 1098121
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: On delay, adjustable: 0 ... 2 s
Potentiometer, left: Light/dark switching
Connection type: Male connector M12, 4-pin


Type: HL18G-F4B3BM
Part number: 1100283
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PUSH/PULL, Light switching
Switching output Q2: PUSH/PULL, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: On delay, adjustable: 0 ... 2 s
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18-B1Y3BB
Part number: 1101315
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 9,000 mm


Type: HL18G-A4A3BM
Part number: 1088546
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: On delay, adjustable: 0 ... 2 s
Connection type: Male connector M12, 4-pin


Type: HL18G-B4B3BP
Part number: 1077133
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Teach-in
Potentiometer, left: Light/dark switching
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18L-P4B5BB
Part number: 1079039
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18L-N1G5BB
Part number: 1080703
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18L-N1G5AB
Part number: 1080702
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-P4A3AB
Part number: 1080461
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-A4A3AD
Part number: 1076151
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-A1E3AA
Part number: 1075726
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 1,000 mm


Type: HL18-B4B2BH
Part number: 1077094
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18-P3A3AD
Part number: 1078873
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-P3A3BB
Part number: 1078776
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-B4B3BA
Part number: 1078610
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18-M1G2AB
Part number: 1078479
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-L1G2AB
Part number: 1078480
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Light switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-L1G3AA
Part number: 1078488
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Light switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18T-M1G3AB
Part number: 1077659
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-P4A3BB
Part number: 1078234
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-B4B3BH
Part number: 1077132
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18L-B4B5BH
Part number: 1077097
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: Sensitivity
Potentiometer, left: Light/dark switching
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18-L5B3AA
Part number: 1077629
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Light switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with connector, Micro (1/2-20), 4-pin, 150 mm


Type: HL18-A2C3BE
Part number: 1082157
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: Not connected
Potentiometer, right: Light/dark switching
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 300 mm


Type: HL18G-V3A3BN
Part number: 1071039
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Health output
Potentiometer, right: Teach-in
Potentiometer, left: Off delay, adjustable: 0 ... 2 s
Connection type: Male connector M8, 4-pin


Type: HL18G-P4A3AL
Part number: 1071036
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18T-P4A3AB
Part number: 1071041
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18T-P3A3AB
Part number: 1071043
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-P4A3AD
Part number: 1071007
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18T-P1G3AB
Part number: 1071042
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Sensitivity
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18G-P1G3AL
Part number: 1071038
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 3 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Teach-in
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-P2B3AA
Part number: 1071049
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: Not connected
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 150 mm


Type: HL18-P2C3AA
Part number: 1071050
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: Not connected
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 300 mm


Type: HL18-N4A3AA
Part number: 1070994
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-B4A3AA
Part number: 1071006
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-P2E3AA
Part number: 1071051
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: Not connected
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with connector M8, 3-pin, 1,000 mm


Type: HL18-A4A3AA
Part number: 1070993
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Dark switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-M5B3AA
Part number: 1071046
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: MOSFET, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with connector, Micro (1/2-20), 4-pin, 150 mm


Type: HL18-P1G3AA
Part number: 1071009
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-N1G3BD
Part number: 1078524
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Cable open end, 2,000 mm


Type: HL18-B3A3BA
Part number: 1078533
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: NPN, Light switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-P3A3BA
Part number: 1078532
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Type: HL18-P4B3BA
Part number: 1078478
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Cable with M12 male connector, 4-pin, 150 mm


Type: HL18-P4A3BD
Part number: 1078751
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: PNP, Light switching
Switching output Q2: PNP, Dark switching
Potentiometer, right: Off delay, adjustable: 0 ... 2 s
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18L-N4A5BA
Part number: 1074774
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 12 m
Light source, light type: Laser, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Dark switching
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M12, 4-pin


Type: HL18-W3A3BA
Part number: 1073691
Product family: SureSense
Product family group: Photoelectric sensors
Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lens
Sensing range: 6.5 m
Light source, light type: PinPoint LED, visible red light
Switching output Q1: NPN, Light switching
Switching output Q2: NPN, Health output
Potentiometer, right: None
Potentiometer, left: None
Connection type: Male connector M8, 4-pin


Ứng dụng

Fields of applications
- Machines with a wide variety of detection tasks
- Detection of transparent objects
- Detection of objects with a wide variety of colors
- Applications with AC power supply
- Detection of small objects and through small openings
- OEM machine construction (e.g., packaging industry, consumer goods, wood processing, etc.)

Examples of application
- Presence monitoring of pallets
- Presence monitoring of pallets
