Cảm biến phản xạ hồi quy Retroreflective sensor - Pepperl+Fuchs - RL39-54/32/40a/82a/116


Product Description
Retroreflective sensor for standard applications, polarization filter, detection range 12 m, red light, sensitivity adjuster, light/dark on, prefault output, PNP output, terminal compartment
General specifications
Effective detection range 0 ... 5 m
Reflector distance 0.1 ... 5 m
Threshold detection range 6 m
Reference target H50 reflector
Light source LED red
Light type modulated visible red light
Polarization filter yes
Ambient light limit IEC / EN 60947-5-2 , 10000 Lux
Functional safety related parameters
MTTFd 800 a
Mission Time (TM) 20 a
Diagnostic Coverage (DC) 0 %
Indicators/operating means
Function indicator LED yellow: switching state
LED red: pre-fault indication
Control elements Sensing range adjuster, light-on/dark-on changeover switch
Electrical specifications
Operating voltage 10 ... 30 V DC
Ripple 10 %
No-load supply current ≤ 20 mA
Time delay before availability ≤ 300 ms
Output
Pre-fault indication output 1 PNP, active when falling short of the stability control
Switching type light/dark on
Signal output 1 PNP output, short-circuit protected, reverse polarity protected, open collector
Switching voltage max. 30 V DC
Switching current max. 200 mA , resistive load
Voltage drop ≤ 3 V
Switching frequency ≤ 300 Hz
Response time ≤ 1.5 ms
Compliance with standards and directives
Directive conformity EMC Directive 2004/108/EC
  EMC Directive 2004/108/EC EN 60947-5-2:2007+A1:2012 IEC 60947-5-2:2007+A1:2012
Standard conformity
  Product standard EN 60947-5-2:2007
IEC 60947-5-2:2007
Approvals and certificates
CCC approval CCC approval / marking not required for products rated ≤36 V
Approvals CE
Ambient conditions
Ambient temperature -25 ... 55 °C (-13 ... 131 °F)
Storage temperature -40 ... 70 °C (-40 ... 158 °F)
Mechanical specifications
Housing width 25 mm
Housing height 64 mm
Housing depth 75 mm
Degree of protection IP67
Connection terminal compartment PG9, ≤ 2.5 mm2
Material
  Housing PBT
  Optical face PMMA
Mass approx. 100 g
General information
Scope of delivery Mounting aid , Reflector
