Bộ điều nhiệt phòng Siemens RDQ400

THÔNG TIN THAM KHẢO

• Danh mục Model sản phẩm SIEMENS

•

  Tất cả danh mục model sản phẩm HVAC của Siemens

• Xem thêm

Siemens RDQ400 là Bộ điều nhiệt phòng, âm tường, dàn lạnh 2 đường ống, điều khiển quạt 3 tốc độ, điều khiển van bật/tắt

Flush mount standalone room thermostat for 2-pipe FCU with 3-speed fan control, on/off valve control


- Tài liệu kỹ thuật của Bộ điều nhiệt phòng Siemens RDQ400 ở đây.

For fan coil unit
- For 2-pipe fan coil units
- LCD backlit display and keylock function
- Operating mode button: Comfort, Protection, and Economy (3s long-press for ECO)
- Operating mode ‘M’ button
- Automatic or manual 3-speed fan control
- Display either room temperature or setpoint
- Support of Chinese standard conduit boxes (max. 78 × 78) with depth ≥ 45 mm (±2) and British metal standard conduit boxes (max. 75 × 75) with depth ≥ 47 mm (±2)
- Adjustable commissioning and control parameters

Thông số kỹ thuật chính của Bộ điều nhiệt phòng Siemens RDQ400

- Operating voltage AC 195.5…253 V, 230 V
- Power consumption 5 VA
- Setpoint setting range 5…40 °C
- Connection cable 2-wire
- Switching differential Heating: 1…1 K; Cooling:
- Relay outputs Fan: (3-speed fan) Q1, Q2, Q3 , Valve: Y12 (N.C.)/Y14 (N.O.)
- Relay outputs, number 5
- Relay output, switching voltage 230 V
- Relay output, switching current 4(2) A
- Degree of protection IP30
- Dimensions (W x H x D) 88 x 88 x 34.5 mm

Accessories (multiple selection) của của Bộ điều nhiệt phòng Siemens RDQ400

ARG70.6
ARG70.6 Adapterplate for thermostats
