Chi tiết thông tin đặc tính sản phẩm
Cảm biến siêu âm Ultrasonic sensor - Pepperl+Fuchs - Ultrasonic sensor UB300-18GM40-E5-V1
Hình ảnh thực tế tham khảo
Đặc tính nổi bật
- Short design, 40 mm
- Function indicators visible from all directions
- Switch output
- 5 different output functions can be set
- Program input
- Temperature compensation
- Thiết kế ngắn, 40 mm
- Chỉ báo chức năng hiển thị từ mọi hướng
- Công tắc đầu ra
- Có thể đặt 5 chức năng đầu ra khác nhau
- Chương trình đầu vào
- Sự cân bằng nhiệt độ
Thông số kỹ thuật datasheet
Product Description |
Single head system |
General specifications |
Sensing range |
35 ... 300 mm |
Adjustment range |
50 ... 300 mm |
Dead band |
0 ... 35 mm |
Standard target plate |
100 mm x 100 mm |
Transducer frequency |
approx. 390 kHz |
Response delay |
approx. 50 ms |
Indicators/operating means |
LED green |
Power on |
LED yellow |
indication of the switching state
flashing: program function object detected |
LED red |
solid red: Error
red, flashing: program function, object not detected |
Electrical specifications |
Operating voltage |
10 ... 30 V DC , ripple 10 %SS |
No-load supply current |
≤ 20 mA |
Input |
Input type |
1 program input
operating distance 1: -UB ... +1 V, operating distance 2: +6 V ... +UB
input impedance: > 4,7 kΩ program pulse: ≥ 1 s |
Output |
Output type |
1 switching output E5, PNP NO/NC, programmable |
Rated operating current |
200 mA , short-circuit/overload protected |
Default setting |
Switch point A1: 50 mm Switch point A2: 300 mm |
Voltage drop |
≤ 3 V |
Repeat accuracy |
≤ 1 % |
Switching frequency |
≤ 13 Hz |
Range hysteresis |
1 % of the set operating distance |
Temperature influence |
± 1.5 % of full-scale value |
Approvals and certificates |
UL approval |
cULus Listed, General Purpose |
CSA approval |
cCSAus Listed, General Purpose |
CCC approval |
CCC approval / marking not required for products rated ≤36 V |
Ambient conditions |
Ambient temperature |
-25 ... 70 °C (-13 ... 158 °F) |
Storage temperature |
-40 ... 85 °C (-40 ... 185 °F) |
Mechanical specifications |
Connection type |
Connector M12 x 1 , 4-pin |
Degree of protection |
IP67 |
Material |
|
|
Housing |
brass, nickel-plated |
|
Transducer |
epoxy resin/hollow glass sphere mixture; foam polyurethane, cover PBT |
Mass |
25 g |
