Pressure switch PBS Hygienic, Dòng công tắc áp suất nhỏ gọn của Sick ứng dụng phụ hợp trong ngành an toàn vệ sinh

The compact pressure switch for hygienic applications
- Công tắc áp suất được phân loại hợp vệ sinh với màn hình hiển thị cho ngành thực phẩm và đồ uống/ Hygienically-graded pressure switch with display for the food and beverage industry
- Các bộ phận được làm ướt được làm từ thép không gỉ 1.4435/ Wetted parts are made from stainless steel 1.4435
- Đầu ra chuyển mạch lập trình riêng và đầu ra tương tự/ Individually programmable switching outputs and analog output
- Giá trị áp suất được hiển thị trên màn hình/ Pressure values are indicated on the display
- Đơn vị giá trị áp suất trong màn hình có thể được chuyển đổi/ Unit of pressure value in the display can be switched
- Trạng thái đầu ra được chỉ báo riêng biệt thông qua đèn LED lớn/ Output states are indicated separately via large LEDs
- IO-Link

Ưu điểm/ Your Benefits

- Vận hành hợp vệ sinh an toàn do màng thép không gỉ có khả năng chịu lực cao, được gắn xả và các kết nối quy trình vệ sinh/ Safe hygienic operation due to flush-mounted, highly resistant stainless steel membrane and hygienic process connections
- Tính phù hợp với CIP và SIP đảm bảo tính sẵn sàng của hệ thống cao/ Suitability for CIP and SIP ensures high system availability
- Thiết lập an toàn và dễ dàng với ba nút bấm lớn và màn hình hiển thị có thể xoay, dễ đọc/ Safe and easy setup with three large pushbuttons and legible, rotatable display
- Vỏ có thể xoay để định tuyến cáp tối ưu/ Rotatable housing for optimum cable routing
- Nhiều cấu hình có sẵn cho phép các giải pháp dành riêng cho khách hàng/ Wide range of available configurations enable customer-specific solutions
- Độ tin cậy cao: Thiết kế chống ăn mòn của các bộ phận và vỏ bị thấm ướt với xếp hạng vỏ bọc IP 65 và IP 67/ High reliability: Corrosion-resistant design of wetted parts and housing with IP 65 and IP 67 enclosure ratings
- Tính khả dụng của hệ thống tối ưu: IO-Link cho phép cài đặt thông số nhanh chóng, đáng tin cậy khi thay đổi sản phẩm/ Ultimate system availability: IO-Link enables fast, reliable parameter setting when changing over products


Overview

The compact pressure switch for hygienic applications
Công tắc áp suất điện tử PBS Hygiene đã được thiết kế để sử dụng trong ngành thực phẩm và đồ uống. Các bộ phận được làm ướt không có khe hở và không có khoảng trống. Bề mặt bằng thép không gỉ chất lượng cao của chúng rất nhẵn và dễ làm sạch. Màng thép không gỉ có độ bền cao được hàn vào kết nối quy trình hợp vệ sinh mà không có khe hở hoặc cạnh./ The electronic pressure switch PBS Hygienic has been designed for use in the food and beverage industry. The wetted parts are gap-free and have no dead spaces. Their high-quality stainless steel surfaces are smooth and easy to clean. The highly resistant stainless steel membrane is welded to the hygienic process connection without gaps or edges.

Thiết bị được thiết kế cho các quá trình CIP và SIP. Điều này cho phép vận hành hợp vệ sinh an toàn kết hợp với thông lượng hệ thống được tối ưu hóa./ The device is designed for CIP and SIP processes. This enables safe hygienic operation in conjunction with optimized system throughput.

PBS Hygiene có sẵn với tối đa hai đầu ra chuyển mạch, một đầu ra tương tự và IO-Link trong một thiết bị duy nhất. Cấu hình trực quan của nó thông qua ba nút bấm lớn và màn hình hiển thị tạo điều kiện thuận lợi cho việc vận hành. Vỏ có thể được xoay theo hai cách, cho phép hiển thị và kết nối điện được căn chỉnh tùy theo tình hình lắp đặt cụ thể. Có sẵn với nhiều dải đo và kết nối quy trình khác nhau, PBS Vệ sinh phù hợp để sử dụng phổ biến./ The PBS Hygienic is available with up to two switching outputs, an analog output and IO-Link in a single device. Its intuitive configuration via three large pushbuttons and display facilitates operation. The housing can be rotated in two ways, allowing the display and electrical connection to be aligned according to specific installation situation. Available with a variety of measuring ranges and process connections, the PBS Hygienic is suitable for universal use.

At a glance
- Công tắc áp suất được phân loại hợp vệ sinh với màn hình hiển thị cho ngành thực phẩm và đồ uống/ Hygienically-graded pressure switch with display for the food and beverage industry
- Các bộ phận được làm ướt được làm từ thép không gỉ 1.4435/ Wetted parts are made from stainless steel 1.4435
- Đầu ra chuyển mạch lập trình riêng và đầu ra tương tự/ Individually programmable switching outputs and analog output
- Giá trị áp suất được hiển thị trên màn hình/ Pressure values are indicated on the display
- Đơn vị giá trị áp suất trong màn hình có thể được chuyển đổi/ Unit of pressure value in the display can be switched
- Trạng thái đầu ra được chỉ báo riêng biệt thông qua đèn LED lớn/ Output states are indicated separately via large LEDs
- IO-Link


Ứng dụng/ Applications

- Các lĩnh vực ứng dụng/ Fields of applications
- Đo lường và giám sát áp suất vệ sinh trong ngành thực phẩm và đồ uống/ Hygienic pressure measurement and monitoring in the food and beverage industry
- Máy chiết rót chai/ Bottle filling machines
- Máy đóng gói/ Packaging machines
- Đo mức thủy tĩnh của chất lỏng trong bồn chứa cao/ Hydrostatic level measurement of liquids in tall tanks

Ứng dụng điển hình/ Examples of application
- Đo mức trong bể chứa/ Level measurement in storage tanks
- Đo áp suất tại bộ trao đổi nhiệt của hệ thống CIP/ Pressure measurement at the heat exchanger of a CIP system
- Cung cấp khí nén trong quá trình thổi/ Supply of compressed air in the blowing process
- Đo mức trong bể chứa/ Level measurement in storage tanks
- Cung cấp khí nén trong quá trình thổi/ Supply of compressed air in the blowing process


Technical overview

Technical data overview
Device type: Pressure switch
Measuring ranges
     Gauge pressure: 0 bar ... 1 bar up to 0 bar ... 25 bar
     Absolute pressure: 0 bar ... 1 bar up to 0 bar ... 25 bar
     Compound pressure: –1 bar ... 0 bar up to –1 bar ... +24 bar
Pressure unit: Bar, MPa, psi and kg/cm2
Accuracy: ≤ ± 1 % of the span
Setting accuracy of switching outputs: ≤ ± 0.5 % of span
Output signal: Switching outputs PNP or NPN, analog output signal plus optional IO-Link
Electrical connection: Round connector M12 x 1


PBSH-RB1X0SHGEEBMA0Z
Part no.: 6051840
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X0ST1S0BMA0Z
Part no.: 6051828
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB010ST1S0BMA0Z
Part no.: 6051832
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB025ST1S0BMA0Z
Part no.: 6051833
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB6X0ST1S0BMA0Z
Part no.: 6051831
Measuring range: 0 bar ... 6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-AB025SD3S0BMA0Z
Part no.: 6066128
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Clamp (DIN 32676) DN 32
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB4X0SD3S0D5A0Z
Part no.: 6063682
Measuring range: 0 bar ... 4 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Clamp (DIN 32676) DN 32
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-CB4X0ST1S0CMA0Z
Part no.: 6063667
Measuring range: –1 bar ... 3 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 0 V ... 10 V
Connection type: M12 round connector x 1, 4-pin

PBSH-CB2X5ST2S0NMA0Z
Part no.: 6061961
Measuring range: –1 bar ... 1.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 0 V ... 10 V
Connection type: M12 round connector x 1, 4-pin

PBSH-RB2X5SHGEEBMA0Z
Part no.: 6051842
Measuring range: 0 bar ... 2.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB010SHGEEBMA0Z
Part no.: 6051844
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X0SHGEED5A0Z
Part no.: 6051859
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB025SHGEEBMA0Z
Part no.: 6051845
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB010SHGEED5A0Z
Part no.: 6051863
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB6X0SHGEENMA0Z
Part no.: 6051880
Measuring range: 0 bar ... 6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X0S54S0BMA0Z
Part no.: 6051834
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB010ST1S0NMA0Z
Part no.: 6051869
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X0ST1S0D5A0Z
Part no.: 6051846
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB6X0ST1S0D5A0Z
Part no.: 6051850
Measuring range: 0 bar ... 6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB025ST1S0D5A0Z
Part no.: 6051852
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB1X0ST2S0BMA0Z
Part no.: 6054503
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X6ST1S0BMA0Z
Part no.: 6051829
Measuring range: 0 bar ... 1.6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB4X0ST1S0BMA0Z
Part no.: 6058750
Measuring range: –1 bar ... 3 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB016ST1S0BMA0Z
Part no.: 6057316
Measuring range: 0 bar ... 16 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB010SD3S0D5A0Z
Part no.: 6062652
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Clamp (DIN 32676) DN 32
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB2X5ST2S0BMA0Z
Part no.: 6060609
Measuring range: 0 bar ... 2.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RP100ST1S0BMA0Z
Part no.: 6059244
Measuring range: 0 psi ... 100 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RP050ST1S0BMA0Z
Part no.: 6059243
Measuring range: 0 psi ... 50 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RP160ST1S0BMA0Z
Part no.: 6059245
Measuring range: 0 psi ... 160 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CP175ST1S0BMA0Z
Part no.: 6059047
Measuring range: –14.5 psi ... 160 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RP200ST1S0BMA0Z
Part no.: 6053827
Measuring range: 0 psi ... 200 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RP300ST1S0BMA0Z
Part no.: 6059246
Measuring range: 0 psi ... 300 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RP025ST1S0BMA0Z
Part no.: 6059242
Measuring range: 0 psi ... 25 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB010ST2S0D5A0Z
Part no.: 6055721
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB016ST2S0D5A0Z
Part no.: 6053664
Measuring range: 0 bar ... 16 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RP015ST1S0BMA0Z
Part no.: 6059241
Measuring range: 0 psi ... 15 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB010SD4S0BMA0Z
Part no.: 6059871
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Clamp (DIN 32676) DN 40
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RP300ST2S0BMA0Z
Part no.: 6059255
Measuring range: 0 psi ... 300 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RP200ST2S0BMA0Z
Part no.: 6059254
Measuring range: 0 psi ... 200 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB025SD4S0BMA0Z
Part no.: 6054657
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Clamp (DIN 32676) DN 40
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB2X5S54S0BMA0Z
Part no.: 6054654
Measuring range: –1 bar ... 1.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RP050ST2S0BMA0Z
Part no.: 6059251
Measuring range: 0 psi ... 50 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RP160ST2S0BMA0Z
Part no.: 6059253
Measuring range: 0 psi ... 160 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RP100ST2S0BMA0Z
Part no.: 6059252
Measuring range: 0 psi ... 100 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CP175ST2S0BMA0Z
Part no.: 6059247
Measuring range: –14.5 psi ... 160 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RP015ST2S0BMA0Z
Part no.: 6059249
Measuring range: 0 psi ... 15 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB010ST2S0BMA0Z
Part no.: 6055517
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RP025ST2S0BMA0Z
Part no.: 6059250
Measuring range: 0 psi ... 25 psi
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB2X5ST1S0BMA0Z
Part no.: 6066092
Measuring range: –1 bar ... 1.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB6X0ST1S0BMA0Z
Part no.: 6066199
Measuring range: –1 bar ... 5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB016SHGEFD5A0Z
Part no.: 6065610
Measuring range: 0 bar ... 16 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: FKM
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB2X5ST2S0NMA0Z
Part no.: 6063256
Measuring range: 0 bar ... 2.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 0 V ... 10 V
Connection type: M12 round connector x 1, 4-pin

PBSH-RB4X0ST1S0BMA0Z
Part no.: 6063762
Measuring range: 0 bar ... 4 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X0SHGEEE5A0Z
Part no.: 6064010
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 2 x NPN
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB1X0S55S0D5A0Z
Part no.: 6063836
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 50 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-AB1X0ST1S0NMA0Z
Part no.: 6071844
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB025SHGEECMA0Z
Part no.: 6071281
Measuring range: –1 bar ... 24 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 0 V ... 10 V
Connection type: M12 round connector x 1, 4-pin

PBSH-CB025SHGEEPMA0Z
Part no.: 6071283
Measuring range: –1 bar ... 24 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: IO-Link/PNP + 0 V ... 10 V
Connection type: M12 round connector x 1, 4-pin

PBSH-CB025SHGEENMA0Z
Part no.: 6071282
Measuring range: –1 bar ... 24 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB010ST1S0Q5A0Z
Part no.: 6071767
Measuring range: –1 bar ... 9 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-AB016SD4S0NMA0Z
Part no.: 6073527
Measuring range: 0 bar ... 16 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Clamp (DIN 32676) DN 40
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB2X5ST1S0GMA0Z
Part no.: 6074514
Measuring range: 0 bar ... 2.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x NPN + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-AB025SD4S0NMA0Z
Part no.: 6073528
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Clamp (DIN 32676) DN 40
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-AB010S54S0BMA0Z
Part no.: 6073509
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X6ST2S0NMA0Z
Part no.: 6074291
Measuring range: 0 bar ... 1.6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 0 V ... 10 V
Connection type: M12 round connector x 1, 4-pin

PBSH-RB010ST1S0Q5A0Z
Part no.: 6074524
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-CB2X5SHGEEBMA0Z
Part no.: 6073289
Measuring range: –1 bar ... 1.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB2X5SHGEFBMA0Z
Part no.: 6075585
Measuring range: –1 bar ... 1.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: FKM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB010SD5S0D5A0Z
Part no.: 6069402
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Clamp (DIN 32676) DN 50
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB1X0SHGEFBMA0Z
Part no.: 6069727
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: FKM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB010SHGEECMA0Z
Part no.: 6068995
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 0 V ... 10 V
Connection type: M12 round connector x 1, 4-pin

PBSH-RB025SHGEED5A0Z
Part no.: 6051864
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin
PBSH-RB025SHGEECMA0Z
Part no.: 6068482
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 0 V ... 10 V
Connection type: M12 round connector x 1, 4-pin

PBSH-CB025SHGEED5A0Z
Part no.: 6068409
Measuring range: –1 bar ... 24 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB025S54S0D5A0Z
Part no.: 6051858
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB1X0S54S0D5A0Z
Part no.: 6051853
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB2X5S54S0D5A0Z
Part no.: 6051855
Measuring range: 0 bar ... 2.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB025S54S0NMA0Z
Part no.: 6051876
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB6X0S54S0D5A0Z
Part no.: 6051856
Measuring range: 0 bar ... 6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB010S54S0D5A0Z
Part no.: 6051857
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB1X6S54S0D5A0Z
Part no.: 6051854
Measuring range: 0 bar ... 1.6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB4X0SHGEEBMA0Z
Part no.: 6059219
Measuring range: 0 bar ... 4 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB016SHGEEBMA0Z
Part no.: 6059751
Measuring range: 0 bar ... 16 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X6SHGEEBMA0Z
Part no.: 6051841
Measuring range: 0 bar ... 1.6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB6X0SHGEEBMA0Z
Part no.: 6051843
Measuring range: 0 bar ... 6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB025SHGEENMA0Z
Part no.: 6051882
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB2X5SHGEED5A0Z
Part no.: 6051861
Measuring range: 0 bar ... 2.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB1X6SHGEED5A0Z
Part no.: 6051860
Measuring range: 0 bar ... 1.6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB6X0SHGEED5A0Z
Part no.: 6051862
Measuring range: 0 bar ... 6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB1X0SHGEENMA0Z
Part no.: 6051877
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB010SHGEENMA0Z
Part no.: 6051881
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X6SHGEENMA0Z
Part no.: 6051878
Measuring range: 0 bar ... 1.6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB2X5SHGEENMA0Z
Part no.: 6051879
Measuring range: 0 bar ... 2.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X0S54S0NMA0Z
Part no.: 6051871
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB2X5S54S0NMA0Z
Part no.: 6051873
Measuring range: 0 bar ... 2.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X6S54S0NMA0Z
Part no.: 6051872
Measuring range: 0 bar ... 1.6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin
PBSH-RB010S54S0NMA0Z
Part no.: 6051875
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB6X0S54S0NMA0Z
Part no.: 6051874
Measuring range: 0 bar ... 6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X6S54S0BMA0Z
Part no.: 6051835
Measuring range: 0 bar ... 1.6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB6X0S54S0BMA0Z
Part no.: 6051837
Measuring range: 0 bar ... 6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB025S54S0BMA0Z
Part no.: 6051839
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB016S54S0BMA0Z
Part no.: 6056022
Measuring range: 0 bar ... 16 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB2X5S54S0BMA0Z
Part no.: 6051836
Measuring range: 0 bar ... 2.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB010S54S0BMA0Z
Part no.: 6051838
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 40 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB025ST1S0NMA0Z
Part no.: 6051870
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB2X5ST1S0D5A0Z
Part no.: 6051849
Measuring range: 0 bar ... 2.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB1X6ST1S0D5A0Z
Part no.: 6051848
Measuring range: 0 bar ... 1.6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB010ST1S0D5A0Z
Part no.: 6051851
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB1X0ST1S0NMA0Z
Part no.: 6051865
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB2X5ST1S0NMA0Z
Part no.: 6051867
Measuring range: 0 bar ... 2.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X6ST1S0NMA0Z
Part no.: 6051866
Measuring range: 0 bar ... 1.6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB6X0ST1S0NMA0Z
Part no.: 6051868
Measuring range: 0 bar ... 6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X0ST2S0D5A0Z
Part no.: 6060763
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-AB010ST1S0BMA0Z
Part no.: 6059517
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB1X0ST1S0BMA0Z
Part no.: 6055177
Measuring range: –1 bar ... 0 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB010ST1S0BMA0Z
Part no.: 6055126
Measuring range: –1 bar ... 9 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB025ST1S0BMA0Z
Part no.: 6058749
Measuring range: –1 bar ... 24 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB2X5ST1S0BMA0Z
Part no.: 6051830
Measuring range: 0 bar ... 2.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X0S55S0BMA0Z
Part no.: 6068066
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 50 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB1X0SHGEFD5A0Z
Part no.: 6068085
Measuring range: 0 bar ... 1 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: FKM
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin
PBSH-CB6X0ST1S0D5A0Z
Part no.: 6067838
Measuring range: –1 bar ... 5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB2X5ST2S0D5A0Z
Part no.: 6067674
Measuring range: 0 bar ... 2.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-RB6X0ST2S0BMA0Z
Part no.: 6067675
Measuring range: 0 bar ... 6 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB4X0ST1S0CMA0Z
Part no.: 6070058
Measuring range: 0 bar ... 4 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 0 V ... 10 V
Connection type: M12 round connector x 1, 4-pin

PBSH-RB025SD3S0BMA0Z
Part no.: 6070377
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Clamp (DIN 32676) DN 32
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB010ST1S0CMA0Z
Part no.: 6070069
Measuring range: 0 bar ... 10 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 0 V ... 10 V
Connection type: M12 round connector x 1, 4-pin

PBSH-RM1X0ST1S0D5A0Z
Part no.: 6052282
Measuring range: 0 MPa ... 1 MPa
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-CB1X0ST1S0D5A0Z
Part no.: 6058780
Measuring range: –1 bar ... 0 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-CB1X0S55S0BMA0Z
Part no.: 6053093
Measuring range: –1 bar ... 0 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Conical coupling (DIN 11851) DN 50 with union nut
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-AB2X5SD3S0BMA0Z
Part no.: 6053626
Measuring range: 0 bar ... 2.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Clamp (DIN 32676) DN 32
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB2X5SHGEFD5A0Z
Part no.: 6058751
Measuring range: –1 bar ... 1.5 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: FKM
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-CB1X0SHGEENMA0Z
Part no.: 6056428
Measuring range: –1 bar ... 0 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: IO-Link/PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB010SHGEFD5A0Z
Part no.: 6054922
Measuring range: –1 bar ... 9 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: FKM
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-CB1X0SHGEEBMA0Z
Part no.: 6055261
Measuring range: –1 bar ... 0 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB025SHGEEBMA0Z
Part no.: 6055155
Measuring range: –1 bar ... 24 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB4X0ST2S0BMA0Z
Part no.: 6054575
Measuring range: 0 bar ... 4 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB4X0SHGEEBMA0Z
Part no.: 6055450
Measuring range: –1 bar ... 3 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB016SHGEEBMA0Z
Part no.: 6054360
Measuring range: –1 bar ... 15 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RP160SHGEEBMA0Z
Part no.: 6054752
Measuring range: 0 psi ... 160 psi
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB010SHGEFBMA0Z
Part no.: 6054655
Measuring range: –1 bar ... 9 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: FKM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-CB010SHGEEBMA0Z
Part no.: 6054696
Measuring range: –1 bar ... 9 bar
Accuracy: ≤ ± 1 % of the span
Process connection: G 1 hygienic flush-mounted
Process temperature: –20 °C ... +125 °C, +150 °C for max. 1 h
Seal: Wetted parts: EPDM
Output signal: 1 x PNP + 4 mA ... 20 mA
Connection type: M12 round connector x 1, 4-pin

PBSH-RB025ST2S0D5A0Z
Part no.: 6060598
Measuring range: 0 bar ... 25 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 2 x PNP + 4 mA ... 20 mA
Connection type: Round connector M12 x 1, 5-pin

PBSH-CB010ST2S0NMA0Z
Part no.: 6067346
Measuring range: –1 bar ... 9 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 2''
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: IO-Link/PNP + 0 V ... 10 V
Connection type: M12 round connector x 1, 4-pin

PBSH-CB1X0ST1S0CMA0Z
Part no.: 6075935
Measuring range: –1 bar ... 0 bar
Accuracy: ≤ ± 1 % of the span
Process connection: Tri-Clamp 1 ½
Process temperature: –20 °C ... +100 °C, +135 °C for max. 1 h
Seal: Without seal
Output signal: 1 x PNP + 0 V ... 10 V
Connection type: M12 round connector x 1, 4-pin
