Đồng hồ điện đa năng Lovato DMG610 | LCD 100-440AC 120-250DC RS485 72X46

THÔNG TIN THAM KHẢO

• Danh mục Model sản phẩm LOVATO ELECTRIC

• Xem thêm

Lovato DMG610 là Đồng hồ điện đa năng LCD 100-440AC 120-250DC RS485 72X46

Flush-mount LCD multimeter, expandable, backlight icon LCD display, 72X46mm/2.8X1.8”, auxiliary supply 100-440VAC/120-250VDC, front optical port and RS485 port

- Type of product: Multifunction digital metering instruments
- Type of installation: Flush mounting
- Type of current connection: CT /5A /1A
- Accuracy active energy measurement: Class 1 (IEC/EN 62053-21)
- Reactive energy: Class 2 (IEC/EN 62053-23)
- Current harmonic analysis: 15th order
- Built-in communication port: RS485
- Expandable: Yes


Order code	DMG610
Weight [g]	320
Qty. per package	1
Multiple qty. of packs per order	1
Package dimensions [mm]	124X104X076
Volume [cm³]	980.096
Bar code [EAN13]	8013975211151
HS Code	90303100



Thông số kỹ thuật DMG610

Product designation				Flush-mount LCD multimeters. expandable
Product type designation				DMG610
Type				Three-phase + neutral
Auxiliary supply Us
Auxiliary rated supply voltage AC			VAC	100…440
Auxiliary rated supply voltage DC			VDC	120…250
Auxiliary operating voltage range
	AC
		min	VAC	90
		Max	VAC	484
	DC
		min	VDC	93.5
		Max	VDC	300
Operational frequency
		min	Hz	45
		max	Hz	66
Power consumption
		Max	VA	9.5
Power dissipation Max			W	3.5
Measuring voltage inputs
Rated voltage (Ue)
		phase-phase	VAC	600
		phase-neutral	VAC	300
Operating voltage range
		phase-phase	VAC	50…720
		phase-neutral	VAC	30…360
Voltage inputs operational frequency
		min	Hz	45
		max	Hz	66
Voltage inputs measurement method				True RMS
Connection method				Single. two. three-phase with or without neutral. balanced three-phase system
Current inputs
Rated current (Ie)			A	1A/5A
Measurement range				0.01…1.2 / 0.01…6
Measurement method				TRMS
Overload capacity				+20% Ie by external CT with 5A secondary
Overload peak			A	50A for 1s
Accuracy
		VLN voltage		±0.5%
		VLL voltage		±0.5%
		Current		±0.5%
		Frequency		±0.05%
		Active power		±0.5%
		Active energy		Class 1 (IEC/EN 62053-21)
		Reactive energy		Class 2 (IEC/EN 62053-23)
RS485 serial interface
Baud rate			bps	Programmable 1200…115200
Insulations
Rated insulation voltage Ui IEC/EN			V	600
Rated impulse withstand voltage Uimp			kV	9.5
Operating frequency withstand voltage			kV	5.2
Functions
Harmonic analysis				15th order
PLC logic				No
Type of communication port				RS485
Ethernet-RS485 gateway function				No
Mechanical features
Housing type				Polyamide
Terminals type				Removable
Conductor cross section
		min	mm²	0.2
		Max	mm²	2.5
		min	AWG	24
		Max	AWG	12
Tightening torque (Max)
			Nm	0.5
			lbin	4.5
Fixing				Flush-mounting
Weight			g	350
Ambient conditions
Temperature
	Operating temperature
		min	°C	-20
		max	°C	+60
	Storage temperature
		min	°C	-30
		max	°C	+80
Relative humidity			%	<90
Maximum Pollution degree				2
Protection degree				IP54
ETIM classification
ETIM 8.0				EC002301 - Multifunction measuring instrument

- Tài liệu kỹ thuật Lovato DMG610 ở đây.
