Bộ chống sét dây tín hiệu Phoenix Contact LIT 2X2-24 - 2804623 |  Analog Digital 2-Kênh

Bộ chống sét dây tín hiệu Phoenix Contact LIT 2X2-24 - 2804623 | Analog Digital 2-Kênh

847
Nhà sản xuất:

Phoenix Contact

;

Xuất xứ: Germany

Giá sỉ:

Giá tốt nhất xem...0909186879 dienelectrics@gmail.com

Khuyến mãi:Có Discount
Bảo hành:12 Tháng (Chính hãng)
Thanh toán:C.O.D / Bảo lãnh TT / Link hoạt
Vận chuyển:Miễn phí Tp.HCM, vùng lân cận
Thông tin nổi bật

Bộ chống sét dây tín hiệu Phoenix Contact LIT 2X2-24 - 2804623 |  Analog Digital 2-Kênh 20kA (8/20)µs ≤1ns

Khả năng chống sét lan truyền cho dây tín hiệu đầu ra Analog/ Digital, 2-kênh theo công nghệ 2 dây dẫn. Đã được thử nghiệm phù hợp với các loại bảo vệ sau trong các khu vực Ex: Ex ia IIC / Ex iaD. Tương thích với HART.


Thông số kỹ thuật

Thuộc tính sản phẩm

IEC test classification C1
C2
C3
D1
Type DIN rail module, one-piece
Product type Surge protection for MCR technology
Surge protection fault message none
Wire pairs per module 2
Insulation characteristics
Overvoltage category III
Pollution degree 2


Thông số kết nối

Connection method Screw connection
Screw thread M3
Tightening torque 0.8 Nm
Conductor cross section flexible 0.2 mm² ... 2.5 mm²
Conductor cross section solid 0.2 mm² ... 2.5 mm²
Conductor cross section AWG 24 ... 14


Thông số Ex

Maximum inner capacitance Ci typ. 1.3 nF
Max. internal inductance Li < 1 µH
Max. input current Ii 350 mA (T4 / ≤ 80°C)
200 mA (T5 / ≤ 50 °C)
150 mA (T6 / ≤ 40 °C)
Max. input voltage Ui 36 V DC
max. input power Pi 3 W
Maximum inner time factor (Ri/Li) 0.2 µs


Thông số kích thước

Dimensional drawing
Width 6.2 mm
Width 6.2 mm
Height 93.1 mm
Height 93.1 mm
Depth 102.5 mm (incl. DIN rail 7.5 mm)
Depth 102.5 mm


Thông số vật liệu

Color anthracite grey RAL 7016
Flammability rating according to UL 94 V-0
Insulating material PBT
Housing material PBT


Thuộc tính về cơ khí
Mechanical data
Open side panel No


Thông số bảo vệ mạch

Direction of action Line-Line & Line-Earth Ground
Maximum continuous voltage UC 36 V DC
25 V AC
Rated current 350 mA (40 °C)
Operating effective current IC at UC ≤ 2 µA
Residual current IPE ≤ 4 µA
Nominal discharge current In (8/20) µs (line-line) 5 kA
Nominal discharge surge current In (8/20) µs (Core-Earth) 5 kA
Pulse discharge current Iimp (10/350) µs (line-earth) 500 A
2 kA (in total)
Total discharge current Itotal (8/20) µs 20 kA
Max. discharge current Imax (8/20) µs maximum (line-line) 10 kA
Max. discharge current Imax (8/20) µs maximum (line-earth) 10 kA
20 kA (in total)
Nominal pulse current Ian (10/1000) µs (line-line) 50 A
Nominal pulse current Ian (10/1000) µs (line-earth) 50 A
200 A (in total)
Output voltage limitation at 1 kV/µs (line-line) spike ≤ 60 V
Output voltage limitation at 1 kV/µs (line-earth) spike ≤ 650 V
Residual voltage at In (conductor-conductor) ≤ 70 V
Residual voltage with Ian (10/1000) µs (line-line) ≤ 50 V
Voltage protection level Up (line-line) ≤ 70 V (C2 - 10 kV / 5 kA)
≤ 50 V (C3 - 10 A)
≤ 55 V (C3 - 50 A)
≤ 80 V (D1 - 500 A)
Voltage protection level Up (line-earth) ≤ 650 V (C1 - 500 V / 250 A)
≤ 700 V (C2 - 10 kV / 5 kA)
≤ 650 V (C3 - 10 A)
≤ 700 V (C3 - 50 A)
≤ 700 V (D1 - 500 A)
Response time tA (line-line) ≤ 1 ns
Response time tA (line-earth) ≤ 100 ns
Input attenuation aE, sym. typ. 0.7 dB (1 MHz / 50 Ω)
typ. 0.3 dB (350 kHz / 150 Ω)
Cut-off frequency fg (3 dB), sym. in 50 Ω system typ. 6 MHz
Cut-off frequency fg (3 dB), sym. in 150 Ω system typ. 2 MHz
Capacity ≤ 1.3 nF (per channel)
Resistance per path 3.3 Ω ±20 %
Surge protection fault message none
Max. required back-up fuse 315 mA (T)
Impulse durability (line-line) C2 - 10 kV / 5 kA
C3 - 50 A
D1 - 500 A
Impulse durability (line-earth) C1 - 500 V / 250 A
C2 - 10 kV / 5 kA
C3 - 50 A
D1 - 500 A
Alternating current carrying capacity (line-earth) 5 A - 1 s


Điều kiện môi trường vận hành và Mức bảo vệ

Ambient conditions
Degree of protection IP20
Ambient temperature (operation) -40 °C ... 80 °C
Ambient temperature (storage/transport) -40 °C ... 80 °C
Altitude ≤ 2000 m (amsl (above mean sea level))


Approval data

Conformity/Approvals
ATEX  II 1 G Ex ia IIC T4...T6
 II 1 D Ex iaD 20 T85°C...135°C
IECEx Ga Ex ia IIC T4...T6
Ex iaD 20 T85 °C...T135 °C


Quy-Chuẩn

Standards/specifications EN 61643-21
Standards/specifications EN 60079-0
Standards/specifications EN 60079-11
Standards/specifications EN 60079-26
Standards/specifications IEC 60079-0
Standards/specifications IEC 60079-11
Standards/specifications IEC 60079-26


Thông số lắp đặt

Mounting type DIN rail: 35 mm


Thông số về thương mại

Item number 2804623
Packing unit 1 pc
Minimum order quantity 1 pc
Sales Key C07
Product Key CL2211
Catalog Page Page 124 (C-4-2019)
GTIN 4046356428309
Weight per Piece (including packing) 76 g
Weight per Piece (excluding packing) 63 g
Customs tariff number 85363010
Country of origin DE


- Tài liệu kỹ thuật (Datasheet) Phoenix Contact LIT 2X2-24 - 2804623 ở đây.


Tham khảo thêm các model khác cùng loại:

LIT 2X2-24 - 2804623

Surge protection in a one-piece 6.2 mm wide DIN rail module for two floating signal circuits in 2-conductor technology. Tested in accordance with the following types of protection in Ex areas: Ex ia IIC / Ex iaD. HART-compatible.


LIT 4X1-24 - 2804649

Surge protection in one-piece 6.2 mm wide DIN rail module for four conductors with common reference potential.


LIT 1X2-24 - 2804610

Surge protection in a one-piece 6.2 mm wide DIN rail module for one floating signal circuit in 2-conductor technology. Tested in accordance with the following types of protection in Ex areas: Ex ia IIC / Ex iaD. HART-compatible.


LIT 2X1-24 - 2804636

Surge protection in one-piece 6.2 mm wide DIN rail module for two conductors with common reference potential.


LIT 4-24 - 2804678

Surge protection in one-piece 6.2 mm wide DIN rail module for four floating signal wires.


LIT 4-12 - 2804704

Surge protection in one-piece 6.2 mm wide DIN rail module for four floating signal wires.


LIT 2-12 - 2804694

Surge protection in one-piece 6.2 mm wide DIN rail module for two floating signal wires. Tested in acc. with the protection types in Ex areas: Ex ia IIC / Ex iaD.
